15W无线充方案
30-40W集成GaN PD充电器PCBA产品
NXP 300W~1000W TEA2017 TEA2095 TEA2209 PC电源方案
NXP 5W wireless charger solution
1. Maximum input power 8W, output 5W
2. The wireless controller has built-in MOS and operational amplifier, with simple peripherals and high cost performance
3. The conversion efficiency is 87%, the system efficiency is 74%, in line with WPC 1.2.3
4. High-precision FOD detection, which can identify foreign objects such as rings
5. Using DSP core, power as low as 10mW
6. Capacity equipment: Iphone8 iphoneX Samsung S8 Note5 etc.
NXP PD3.0 QC4.0 QC4.0 PPS Multi-port travel charger solution
1. The total power is 30W, the maximum output of port C is 27W, and the maximum output of port A is 12W. The two ports work at the same time and automatically allocate power output. By adjusting the power device, it can be upgraded to 65W, and the protocol board can be upgraded to 4-port output.
2. The C port supports USB PD3.0, QC4.0/3.0/2.0, BC1.2 multiple protocols.
3. The system hardware integrates 20 abnormal protection modes to ensure system safety to the greatest extent.
4. A single protocol chip can implement multiple protocols, improving system flexibility and platform consistency.
5. Compatible devices: Iphone6/7/8/X, Ipad/Macbook/Pro, Samsung S8/S6, Huawei Mate9 P9, Xiaomi 6, etc.
NXP PD3.0 QC4.0 QC4.0 PPS Power turnkey solution
1. Support USB PD3.0, QC4.0/3.0/2.0, BC1.2 multiple protocols. The maximum output power is 27W, which can be upgraded to 18W, 45W and 65W by adjusting the protocol and peripheral power devices.
2. Meet all DO EU-CoC Tier2 energy efficiency requirements (>91%@12V/2.1A or 5V/5A) no-load standby power consumption <30mW).
3. The system hardware integrates 20 abnormal protection modes to ensure system safety to the greatest extent.
4. A single protocol chip can implement multiple protocols, improving system flexibility and platform consistency.
5. Compatible devices: Iphone6/7/8/X, Ipad/Macbook/Pro, Samsung S8/S6, Huawei Mate9 P9, Xiaomi 6, etc.
NXP TEA1755 PFC Flyback 75W~150W功率电源方案
1. Support 1 string to 13 string lithium battery charging, the maximum power can reach 150W
2. Built-in PFC controller, in line with safety certification and various energy efficiency standards
3. Optional output protocol (PD protocol or custom private protocol)
4. Perfect protection mechanism (overvoltage, overtemperature, overcurrent, short circuit protection, overcharge and anti-reverse connection, etc.)
5. High power density, small size, no need for fan for heat dissipation
6. Intelligent control of lithium battery charging to ensure charging safety and prolong battery life. At the same time, it can be reserved for upgrading and customizing personalized functions.
NXP TEA1916 LLC High power solution
1. It supports charging of lithium batteries from 7 to 24 strings, and the maximum power can reach 500W
2. There is no auxiliary power supply, which reduces costs and meets safety standards and various energy efficiency standards
3. LLC has high efficiency, small heat generation, and superior EMI performance
4. Built-in X-capacitor discharge function, safe, low standby power consumption
5. The power density is large, the volume is small, and there is no need for a fan to dissipate heat
6. Perfect protection mechanism (overvoltage, overtemperature, overcurrent, short circuit protection, overcharge and anti-reverse connection, etc.)
7. MCU intelligently manages lithium battery charging to ensure charging safety and prolong battery life. At the same time, it can reserve upgrades and customize personalized functions
NXP TEA2017 TEA2095 TEA2206 INN650DA260A 150W PD GaN充电器方案
NXP&Southchip wireless charger power bank
1. The mobile power supply adopts Buck-boost SC8913, the maximum power is 24W
2. Support PD2.0 (two-way) and USB-A port output, wireless charging output power 5W, upgrade protocol chip, you can upgrade to PD3.0 PPS.
3. Built-in MCU control, freely switch wireless and wired charging and discharging
4. Built-in multiple protection modes such as over current, over temperature, over voltage, short circuit protection, etc.
5. PD compatible devices: iphone8 iphoneX Macbook, Samsung S8 Huawei Mate9/P9, etc.
6. Wireless charging compatible devices: Iphone8, iphoneX, Samsung S8 Note5, etc.
交错式PFC超薄大功率电源NXP TEA2376 PCBA产品
(1)输入90Vac-264Vac,输出28V/300W
(2)尺寸:158mm*77mm*13.8mm高(PCB板上10mm)
(3)效率95.5%(100%载)at 230Vac输入,95% at 115Vac输入
(4)PF>0.96 at 50%载(264Vac),>0.91 at 30%载(264Vac)
Southchip&OB PD Solution
1. Support PD, QC3.0
2. Two-way Type-c
3. Cypress CCG2, CCG3 PD protocol chip
4. With battery protection balance
5. Support common A port QC3.00
Southchip&OB Car ignition
1. Support PD, QC3.0
2. Double A port 5V 2A
3. 888 digital tube display
4. With battery protection balance
5. Double cigarette lighter
Southchip&OB graphene QC solution
1. 3 2000mAh 18650 graphene cells
2. 12V 10A DC charging, 10 minutes full
3. Support QC discharge
4. Support 5V 2A discharge of ordinary usb-a port
5. Protection and balance function
南芯SC3057 SC3503 SC2151A-65W集成GaN PD充电器方案
Southchip SC8701
1.60W PD
2. Support QC3.0
3. Support BC1.2, Apple Samsung
4. Up to 8 5V 2.4A USB-A
5. Large current
Southchip SC8701 car chargr PD solutionu
1.60W PD
2. Support QC3.0, MTK PE, FCP, Apple Samsung BC1.2
3. High efficiency buck-boost conversion
4. Dynamic adjustment of output voltage
5. Ultra-wide input voltage range: 2.7 V to 36V (40V peak voltage)
Southchip drone charger
1. High power output up to 88W
2. High efficiency buck-boost conversion
3. Light load automatically enters power saving mode
4. Support normal A port discharge
5. Synchronous 4-pipe buck-boost controller
Southchip SC8803&OB OB wall chargter QC solution
1. Wall charging mobile power supply
2. Support filling and discharging at the same time
3. Support QC discharge
4. Support common A-port discharge
5. Efficiency up to 95%
wireless power bank
1. Using MCU IP5310 NXP (NXQ1TXH5) wireless charging architecture 2. Type-C input interface, 1 Micro USB input interface, 2 USB A output interfaces
3. Support WPC 1.2 QI standard
4. Integrated high-efficiency full-bridge power MOS
5. Few external components are required, minimizing cost and board space
6. Standby (waiting state) power 10 mW (typical)
7. Smart Power Limit (SPL) function to adapt to the limited output 5 V power supply
8. Support over current, over voltage, over temperature protection
Application areas: smart phones, game consoles, notebooks and other portable electronic devices
Car ignition PCBA
1. QC output
2. Buck reverse discharge output
3. With battery protection balance
4. Support ordinary double A port discharge
5. Monitoring of charge and discharge status, undervoltage and overvoltage protection
